What should I pay attention to when installing the shower?
- Date：2021-10-07
- Read：1717
1. First, carefully read the sprinkler installation instructions;
2. Measure the size from left to right, up and down to determine the best position for installing the shower;
3. According to the specific height, mark the appropriate height to be installed on the wall;
4. Punch holes on the wall according to the marked position;
5. Screw down the round bottom cover in the fitting on the wall with screws to ensure that it is tightened to avoid the falling off of the shower in future use;
6. Install the shower rod on the wall, first stabilize the upper fixing point, and then fix the lower position;
7. After determining that all the internal angle screws at the upper fixing point are screwed in, make detailed adjustment;
8. Tighten the hose sleeve of the shower and install the hand-held shower.
Precautions for sprinkler installation:
(1) Determine the installation height of the shower. Sprinkler is mainly divided into concealed sprinkler and open sprinkler. The installation height of concealed shower is that the wall is concealed, the distance between the center of water outlet and the ground shall be 2.1m, and the distance between the center of shower switch and the ground is preferably 1.1m. The surface mounted shower is generally defined by the water surface of the shower, and the installation height of the shower is preferably 2m from the ground. It can be adjusted according to the height of the family during actual installation.
(2) Protect hardware such as faucet. When tightening the faucet, a thick cloth or plastic film can be wrapped around the screw cap of the faucet to prevent the faucet from being scratched by the wrench.
(3) Pay attention to the internal structure of the wall. Before installation, the location of waterways and circuits can be marked on the wall to avoid breaking the water pipe during drilling.
(4) Determine the hole spacing and height of cold and hot water. Generally, the distance between the cold and hot water center holes of the shower faucet on the market is 15 cm, and there will be two s joints inside. The distance can be adjusted appropriately, and the error cannot exceed 1 cm.
Precautions for concealed sprinkler:
(1) Be sure to embed it during hydropower transformation, that is, purchase showers and send them to the decoration site before hydropower transformation construction.
(2) Concealed installation shall be carried out according to the requirements of the manual. Some concealed sprinklers may have special requirements.
(3) Because the valve core of the faucet should be buried in the wall, pay attention to the thickness of the toilet wall, and do not bury the valve core where the wall is too thin, because it can not be well embedded. When embedding the valve core, pay attention not to take off the protective cover of the valve core, so as to protect the faucet valve core. When embedding, pay attention to the up, down, left and right directions of the valve core to avoid wrong embedding.
(4) The bottom of the slotted part must be waterproof to prevent leakage or condensation of the embedded part of the sprinkler from affecting the wall.
